Description
GE DS3800HMPJ1A1D
Technical Specifications
- Product Series: GE Series Six / DS3800.
- Revision: 1A1D.
- Board Type: Control / Processing Module.
Functional Features
- Logic Execution: Processes discrete and analog control algorithms.
- I/O Management: Interfaces with Series Six I/O racks for field data acquisition.
- Diagnostics: Features onboard LEDs and test points for troubleshooting.
Application Scenarios
Legacy power plant controls, industrial manufacturing, and system maintenance/upgrades.
Performance Parameters
- Processing Speed: Deterministic scan rates for real-time control.
- Compatibility: Strictly matches 1A1D revision system requirements.
Material Composition
Multi-layer PCB with through-hole and surface-mount components, conformal coated for environmental protection.
Structural Characteristics
Standard DS3800 form factor with edge connector and front-panel test points.
Working Principle
Executes control logic, reads field inputs via the backplane, and updates outputs based on the programmed sequence.
Installation Requirements
- Align carefully with backplane guides.
- Secure with mounting hardware if required by the chassis.
Usage Precautions
- Do not substitute with different revision boards without validation.
- Power down the rack before installation.
