Description
GE IS200TPROH2C
Technical Specifications
- Part Number: IS200TPROH2C
- Series: Mark VI
- Manufacturer: General Electric
- Product Type: Turbine Protection Board
Functional Features
- Protection Monitoring: Continuously monitors critical turbine parameters.
- Trip Logic: Executes protective trip commands when limits are exceeded.
- Redundancy: Supports redundant protection architectures for high reliability.
- Diagnostics: Provides protection system health diagnostics.
Application Scenarios
- Turbine Safety: Critical safety system in gas and steam turbines.
- Mark VI Systems: Integral to Mark VI turbine protection systems.
- Power Generation: Ensuring safe operation of power generation equipment.
Performance Parameters
- Response Time: Fast response for immediate protection.
- Reliability: Extremely high reliability for safety-critical applications.
- Availability: High availability with redundant designs.
Material Composition
- PCB: Industrial-grade PCB with safety-rated components.
- Relays: High-reliability relays for trip output circuits.
Structural Characteristics
- Form Factor: Standard Mark VI board form factor.
- Indicators: Status LEDs for protection system health.
Working Principle
The board continuously monitors input signals from critical sensors. If a parameter exceeds a predefined safe limit, the board activates trip relays to shut down the turbine safely, independent of the main control system.
