GE IS210AEBIH1B
GE IS210AEBIH1B - Image 2

GE IS210AEBIH1B

Product Introduction:

  • The IS210AEBIH1B is an AE (Application/Ethernet) bridge interface board designed for GE Mark VI/Mark VIe turbine control systems. It provides bridging and communication between subsystems and is commonly used in wind turbine control assemblies. Its role is to ensure stable communication between control modules and turbine subsystems.
Request Quote
Category: SKU: GE IS210AEBIH1B

Description

GE IS210AEBIH1B

  • Technical Specifications:
    • Series: GE Mark VI / Mark VIe
    • Board Type: AE Bridge Interface Board
    • Dimensions: Long, narrow rectangular board
    • Weight: Approximately 0.34 kg (0.75 lb) before packaging
    • Connectors:
      • One right-angle connector along one short edge
      • Seven vertical pin connectors
      • Multiple three-position plug connectors
    • Mounting: Drilled holes in corners and within the body for multiple installation options
  • Functional Features:
    • Provides AE bridge functionality to enable data exchange between control and turbine subsystems
    • Supports communication interfaces to other boards within the control rack
    • Compact board footprint suitable for space-constrained assemblies
    • Reference designators and part numbers marked on the board for identification
  • Application Scenarios:
    • Wind turbine control systems (pitch control, converter, main turbine controller)
    • Gas/steam turbine control racks where bridging between subsystems is required
    • Industrial automation requiring reliable bridge interfaces in distributed control systems
  • Performance Parameters:
    • Designed for high-reliability communication in turbine environments
    • Supports industrial temperature ranges and vibration conditions typical of turbine enclosures
  • Material and Structural Characteristics:
    • High-quality PCB material with industrial-grade components
    • Robust connectors for repeated mating cycles
    • Mounting holes and brackets for secure attachment to chassis or backplanes
  • Working Principle:
    • Acts as a communication bridge, routing signals and data between the main control processors and auxiliary I/O or application-specific boards. It ensures data integrity and timing compatibility between subsystems.
  • Installation Requirements:
    • Mount securely using provided mounting holes and hardware
    • Align and seat connectors carefully to avoid pin damage
    • Ensure rack power is off during installation or follow hot-swap procedures if supported
    • Verify correct board orientation and slot assignment per system documentation
  • Usage Notes:
    • Handle with care; avoid bending connectors or subjecting the board to mechanical shock
    • Use ESD protection during handling and installation
    • Periodically inspect connector mating and secure mounting
    • Confirm compatibility with the specific Mark VI/VIe software version
