GE PQMII-T20-C
GE PQMII-T20-C - Image 2

GE PQMII-T20-C

Product Overview: The GE PQMII-T20-C is a variant of the PQMII-T20 power quality meter, featuring specific hardware or firmware configurations tailored for particular applications or regional standards. It provides the same comprehensive power quality monitoring capabilities as the base model.

Request Quote
Category: SKU: GE PQMII-T20-C

Description

GE PQMII-T20-C Technical Specifications:

  • System Compatibility: Three-phase AC networks.
  • Communication: ModBus RTU.
  • I/O: Analog outputs, digital inputs, relay outputs.

Functional Features:

  • Power Quality Analysis: Voltage, current, power, harmonics, transients.
  • Event Capture: Waveform and event recording.
  • Control Logic: Programmable setpoints and relay outputs.

Application Scenarios:

  • Industrial power quality monitoring.
  • Harmonic troubleshooting.
  • Energy management.

Performance Parameters:

  • Accuracy: High-precision measurements.
  • Sampling: High-speed for transient capture.
  • Storage: Event and waveform logging.

Material Composition & Structural Characteristics:

  • Enclosure: Industrial-grade housing.
  • Display: Front-panel display and keypad.
  • Connectors: Screw terminals for field wiring.

Working Principle: Samples and digitizes voltage/current signals, processes with DSP, calculates parameters, and outputs data or triggers relays based on setpoints.

Installation Requirements:

  • Wiring: Correct CT/PT polarity, shielded communication cables.
  • Grounding: Proper grounding.

Usage Precautions:

  • Configuration: Software-based setup.
  • Safety: De-energize CTs before wiring changes.
  • Maintenance: Periodic verification and inspection.
