Description
GE SL463RG
Technical Specifications
- Frame Type: SL Series
- Amperage Rating: 600 Amperes (Standard configuration)
- Poles: 3 Poles
- Voltage Rating: 600V AC Maximum
Functional Features
- Provides robust thermal-magnetic protection against overloads and short circuits.
- Features aluminum/copper load and line lug terminal types.
- Engineered for field replacement, retrofits, and system expansions.
Application Scenarios
Extensively utilized in main power distribution panels, heavy industrial manufacturing facilities, and large commercial infrastructure.
Performance Parameters
- Capable of handling massive fault currents safely.
- Precision-engineered trip mechanisms ensure accurate and fast response.
Material Composition
Housed in a high-strength, flame-retardant thermoset plastic enclosure with high-conductivity copper/aluminum internal busbars and silver-alloy contacts.
Structural Characteristics
Compact molded case design with standardized dimensions for seamless integration into existing switchgear. Features an external toggle handle for manual operation.
Working Principle
Operates using a thermal-magnetic tripping mechanism. The thermal element responds to sustained overloads via a bimetallic strip, while the magnetic element provides instantaneous tripping during severe short-circuit conditions.
Installation Requirements
- Must be installed by qualified electricians in accordance with local electrical codes.
- Requires proper torque specifications on line and load lugs.
- Ensure adequate ventilation and clearance around the breaker.
Usage Precautions
- Always de-energize the panel before installation or maintenance.
- Never exceed the rated voltage or amperage capacity.
- Perform regular maintenance testing.
