ICS Triplex T8151

ICS Triplex T8151

Product Introduction: The T8151 is an intelligent communication interface module that provides multiple communication services for Trusted TMR controllers. This module acts as a relay between the processor, other Trusted systems, engineering workstations, and third-party equipment. It significantly reduces the communication burden on the triple modular redundant processor by handling all external communication tasks independently.

Request Quote
Category:

Description

ICS Triplex T8151

Technical Specifications:

  • Processor: Motorola PowerPC processor
  • Ethernet Interface: 2 x 10/100BaseT ports
  • Serial Interface: 2 x RS-232/422/485, 2 x RS-422/485, 1 x RS-232 diagnostic port
  • Communication Protocols: Modbus RTU, Open Modbus TCP, Trusted Peer to Peer, Trusted Enhanced Peer to Peer, ICS2000, CP2000
  • Backplane Power Supply: 20 VDC to 32 VDC
  • Power Consumption: 10 W typical
  • SOE Buffer: 4000 events
  • Baud Rates: 1200 baud to 115200 baud
  • Dimensions: 266 mm height x 31 mm width x 303 mm depth
  • Weight: 1.13 kg

Functional Features:

  • Independent PowerPC processor handles all communication messages
  • Prevents external read and write operations from consuming TMR controller computing resources
  • Fully isolated multi-channel hardware with galvanic isolation
  • No crosstalk between communication channels
  • Resistant to on-site static electricity and radio frequency interference
  • Native multi-protocol support without additional gateways
  • Front-panel serial diagnostic port
  • Front-panel fault and status indicator LEDs
  • Online configuration activation capability

Application Scenarios:

  • Safety instrumented systems requiring Modbus communication
  • Integration with third-party PLCs and DCS systems
  • Engineering workstation connectivity
  • Peer-to-peer communication between Trusted systems
  • Sequence of events recording and transmission

Performance Parameters:

  • Operating temperature range from 0°C to +60°C
  • Storage temperature range from -25°C to +70°C
  • Relative humidity from 10% to 95% non-condensing
  • Response time less than 1 ms for high dynamic control

Material Composition:

  • High-grade industrial electronic components
  • Conformal coating option available for harsh environments
  • Durable front-panel connectors

Structural Characteristics:

  • Single printed circuit board design
  • Integrated serial ports on mainboard
  • Front-panel diagnostic interface
  • LED status indicators for module health and operational mode

Working Principle: The module operates on the Trusted operating system with a high-speed kernel providing memory management and basic services. A modular watchdog monitors processor operation and power supply unit output voltage. Dual redundant power inputs from the chassis backplane ensure continuous operation. The onboard power supply unit provides voltage conversion and power regulation.

Installation Requirements:

  • Install in T8100 or T8300 I/O module slot
  • Proper chassis grounding mandatory
  • Ethernet cables must be shielded and properly terminated
  • Serial cable shielding must be connected at one end only

Usage Precautions:

  • Take proper ESD precautions before installation
  • Do not touch connector pins directly
  • Inspect module for physical damage before installation
  • Secure ejector latch fully after insertion
  • Record fault codes before performing fault reset
  • Firmware upgrades should be performed by qualified personnel
