Product Introduction: The T8153C is a communication interface adaptor module within the ICS Triplex Trusted TMR system. The “C” suffix indicates a conformal-coated variant for enhanced environmental protection. This module provides communication interface access and gateway module connectivity, connecting directly to the rear of the companion communication interface module (T8151B). It provides multiple high-speed communication ports for system integration with external devices, engineering workstations, and third-party equipment.

Request Quote
Category:

Description

ICS Triplex T8153C

Technical Specifications:

  • Brand: ICS Triplex (Rockwell Automation)
  • Model: T8153C
  • Type: Trusted Communication Interface Adaptor (Conformal Coated)
  • Ethernet Ports: 2 × 100Mbps Ethernet connections
  • Serial Ports: 4 × RS422/485 connections, 2 × RS232 connections
  • Power Supply: 24VDC
  • Power Consumption: 50W
  • Operating Temperature: -40°C to +85°C
  • Dimensions: 300mm × 200mm × 100mm
  • Weight: 5kg
  • Redundancy: Triple Modular Redundancy (TMR)
  • Safety Level: SIL4 performance capability
  • Fault Switching Time: ≤1ms

Functional Features:

  • Provides communication interface access for Trusted TMR system communication modules
  • 2 × 100Mbps Ethernet ports for high-speed network connectivity
  • 4 × RS422/485 ports for serial communication with field devices and third-party systems
  • 2 × RS232 ports for local configuration and diagnostics
  • Triple redundant (TMR) design with three independent processor and execution units per channel
  • Hardware Implemented Fault Tolerance (HIFT) architecture with rapid fault identification and response
  • Fault-tolerant (3-2-0) operation capability
  • High-performance processor supporting complex control logic and high-speed data processing
  • Modular design supporting multi-channel expansion
  • Supports Modbus and other industrial communication protocols
  • Conformal coating for protection against moisture, dust, and corrosive atmospheres

Application Scenarios:

  • Industrial automation: monitoring production line equipment status including machine operation, conveyor position, and valve switching
  • Safety systems: processing signals from emergency stop buttons, fire alarm buttons, and other safety devices
  • Connecting Trusted systems to engineering workstations and third-party devices
  • Communication gateway functions between Trusted systems and external networks
  • Oil & gas, petrochemical, and power generation process control

Performance Parameters:

  • Redundancy: Triple Modular Redundancy (TMR)
  • Safety Performance Level: SIL4
  • Fault Switching Time: ≤1ms
  • Ethernet Speed: 100Mbps
  • Operating Temperature: -40°C to +85°C

Material Composition:

  • Industrial-grade multi-layer PCB with conformal coating
  • High-reliability semiconductor components
  • Precision-machined connectors
  • Metal chassis

Structural Features: The T8153C connects directly to the rear of the T8151B communication interface module, providing additional communication port access. The module is installed in the Trusted controller chassis and connects to the triplicated inter-module bus through the backplane.
