ICS Triplex T8480C

ICS Triplex T8480C

Product Introduction: The T8480C is a high-reliability industrial safety analog output module within the ICS Triplex Trusted TMR system. The “C” suffix indicates a conformal-coated variant, providing enhanced protection against moisture, dust, and corrosive environments. The module provides 40 channels of TMR analog output and is designed for safety-critical industrial control applications requiring SIL3 certification.

Request Quote
Category:

Description

ICS Triplex T8480C

Technical Specifications:

  • Brand: ICS Triplex (Rockwell Automation)
  • Model: T8480C
  • Type: Trusted TMR Analog Output Module (Conformal Coated)
  • Channels: 40 analog output channels
  • Architecture: Triple Modular Redundancy (TMR)
  • Safety Certification: IEC 61508 SIL3 (TÜV certified)
  • System Power Supply: 20 to 32VDC
  • Response Time: <2ms
  • Accuracy: ±0.1%
  • Communication Interfaces: Ethernet, PROFIBUS, Modbus
  • SOE Resolution: 1ms

Functional Features:

  • Triple redundant architecture ensures continuous operation even with single-channel failure
  • High diagnostic coverage with comprehensive self-diagnostic functions for rapid fault identification and isolation
  • High measurement accuracy of ±0.1% ensures system precision
  • Fast response time captures transient events reliably
  • Supports multiple communication protocols including Ethernet, PROFIBUS, and Modbus
  • Conformal coating provides protection against harsh environmental conditions
  • Hardware Implemented Fault Tolerance (HIFT) with voting functionality
  • 1ms SOE event recording for precise event sequencing
  • Online hot-swap capability via adjacent slot or smart slot configuration
  • Front panel LED indicators for channel status and module health

Application Scenarios:

  • Safety Instrumented Systems (SIS)
  • Emergency Shutdown Systems (ESD)
  • Fire and Gas Detection Systems (F&G)
  • Boiler control systems
  • Power plant control systems
  • Oil & gas process control
  • Chemical process automation

Performance Parameters:

  • Safety Integrity Level: SIL3 (IEC 61508)
  • Channel Count: 40
  • Response Time: <2ms
  • Accuracy: ±0.1%
  • SOE Resolution: 1ms

Material Composition:

  • Industrial-grade multi-layer PCB with conformal coating
  • High-precision digital-to-analog converters
  • Opto-isolation barriers for channel-to-system protection
  • Precision-machined metal enclosure

Structural Features: Standard Trusted I/O module form factor, inserted into available I/O slots of the Trusted I/O chassis. Mechanical keying prevents insertion into incorrect slots. Front panel features channel status LEDs and module-level fault/health indicators. Field connections are made through removable Field Termination Assemblies (FTA).

Working Principle: The TMR architecture processes each analog output command through three independent channels. A hardware voter determines the correct output state based on majority agreement. Each output channel contains a voting array for the output switch, providing fault-tolerant uninterrupted control even under output switch fault conditions.

Installation Requirements:

  • Install in Trusted I/O chassis with adequate ventilation
  • Maintain proper spacing for airflow and service access
  • Use recommended Field Termination Assemblies and follow isolation specifications
  • All field wiring to use ferruled conductors with correct labeling
  • Route analog output wiring separately from VFD and high-current cables

Usage Notes:

  • Disconnect load power before making wiring changes
  • Verify permissive and bypass status during hot-swap operations
  • Follow Management of Change (MOC) and Lockout/Tagout (LoTo) procedures
  • Perform regular channel function tests and check terminal tightness
  • Use dry air for routine maintenance dust removal
  • Keep at least one spare module per cabinet, stored in anti-static packaging
