Product Introduction: The T9832 is an analogue input termination assembly within the ICS Triplex AADvance product family. It is designed to provide organized and protected field wiring termination for analogue input signals connected to AADvance control systems. The dual configuration designation indicates enhanced channel capacity or redundancy support for critical measurement loops.

Request Quote
Category:

Description

ICS Triplex T9832

Technical Specifications:

  • Type: Analogue Input Termination Assembly
  • Configuration: Dual channel arrangement
  • System Compatibility: AADvance series control systems
  • Module Pairing: Designed for use with T9432 Analogue Input Modules

Functional Features:

  • Dedicated analogue signal termination points for field instrument connections
  • Dual configuration supporting paired or redundant input channels
  • Organized terminal layout for simplified field wiring
  • Compatibility with standard industrial analogue signals
  • Rugged construction for industrial environment deployment

Application Scenarios:

  • Process variable measurement termination in chemical plants
  • Temperature and pressure transmitter connections
  • Flow meter signal routing in pipeline systems
  • Tank level sensor wiring termination
  • Analytical instrument interface connections

Performance Parameters:

  • Signal Type: Standard 4-20 mA and voltage signals
  • Termination Capacity: Multiple channels per assembly
  • Compatibility: Matched to T9432 module specifications

Material Composition:

  • Housing: Industrial-grade metal or high-strength polymer
  • Terminal Blocks: Plated screw terminals for corrosion resistance
  • PCB: Conformal coated for moisture protection

Structural Characteristics:

  • Compact DIN rail mountable form factor
  • Clear channel identification marking
  • Shield termination points for noise immunity
  • Rugged mechanical construction

Working Principle: The T9832 receives analogue signals from field-mounted process instruments through dedicated terminal points. The signals are conditioned and routed to the connected T9432 analogue input module for conversion and processing by the AADvance controller. The dual configuration provides flexibility for either expanded channel count or redundant measurement applications.

Installation Requirements:

  • Mount on standard DIN rail in industrial enclosures
  • Connect shielded cables for noise-sensitive analogue signals
  • Pair with appropriate T9432 module per system design
  • Verify signal polarity before energizing circuits

Usage Precautions:

  • Do not exceed rated voltage or current per channel
  • Maintain shield integrity for noise immunity
  • Verify terminal tightness periodically
  • Inspect for corrosion in humid environments
