ICS Triplex‑TC‑201‑02‑4M5 Cable Assembly
Technical Specifications:
- Cable Total Length: 4.5 m
- Connector Type: Dual‑ended 12‑pin locking ODU circular connectors
- Conductor Structure: Multi‑strand tinned copper conductors
- Shielding Structure: Overall braided copper shielding layer
- Insulation Material: Industrial‑grade flame‑retardant PVC insulation
- Operating Voltage Rating: 300 V
- Operating Temperature Range: −20 °C ~ +70 °C
- Minimum Bending Radius: 10 × cable outer diameter
- Net Weight: 0.42 kg
- Compatibility: Matches T8312 expander interface adapter and Trusted expander chassis port
Functional Features:
- Factory pre‑terminated both‑end ODU locking connectors, no field soldering or crimping operation required
- Heavy‑duty braided shielding suppresses industrial electromagnetic interference
- Lock‑type ODU connectors prevent accidental disconnection under mechanical vibration
- Designed for TMR high‑speed differential communication signal transmission
- Flame‑retardant cable material satisfies industrial site fire‑safety requirement
- Strict impedance matching design guarantees stable 1.5 Mbps communication signal transmission quality
Application Scenarios: Main‑chassis to expander‑chassis interconnection inside Trusted safety instrument system, petrochemical SIS multi‑chassis wiring, thermal‑power safety system rack expansion connection, offshore platform safety‑system inter‑rack cabling, installation sites requiring 4.5‑meter expander link distance.
Material Composition:
- Conductors: Multi‑strand tinned copper wires
- Inner insulation: Flame‑retardant PVC compound
- Shielding layer: Copper‑alloy braided shielding mesh
- Outer jacket: Abrasion‑resistant flame‑retardant PVC outer sheath
- Connectors: ODU 12‑pin circular gold‑plated contact assemblies, metal locking shell
- Strain‑relief components: Rubber strain‑relief sleeves at cable‑connector transition position
Structural Characteristics: Complete pre‑assembled cable assembly. Two cable ends are fitted with 12‑pin ODU circular locking connectors. Internal multi‑pair differential signal conductors are arranged, wrapped by full‑coverage braided shielding layer. Outer abrasion‑resistant protective jacket covers whole cable length. Strain‑relief structure eliminates mechanical stress transfer to internal conductor‑connector joint points.
Working Principle: Transmits differential TMR communication signal from T8312 adapter port to expander chassis communication port. Braided shielding layer diverts external electromagnetic noise to grounding potential, avoids noise coupling into differential signal pairs. Matched characteristic impedance ensures signal integrity for 1.5 Mbps high‑speed inter‑chassis data transmission.
Installation Requirements:
- Align connector pin notch, insert ODU connector fully and rotate locking ring until complete lock engagement.
- Reserve cable laying slack, avoid applying tensile pulling force onto cable‑connector joint.
- Maintain cable bending radius larger than minimum allowable bending radius during routing.
- Route expander communication cable separately away from high‑voltage power cables.
- Connect cable shielding terminal to chassis protective grounding point according to official grounding drawing.
Usage Notes:
- Do not use non‑original substitute cables. Impedance mismatch will cause inter‑chassis communication error.
- Do not drag cable by pulling connector housing. Mechanical damage will occur inside connector contact parts.
- Avoid placing cable close to high‑temperature equipment surfaces. High temperature accelerates outer jacket aging.
- Periodically inspect connector locking state and cable outer‑jacket integrity for vibration‑intensive working locations.
