Description
KOLLMORGEN 6SM57M-3.000
Technical Specifications:
- Brand: KOLLMORGEN
- Model: 6SM57M-3.000
- Product Type: Brushless AC Servo Motor
- Frame Size: NEMA 23
Functional Features:
- High Torque Density: Delivers exceptional continuous and peak torque in a compact package.
- Smooth Operation: Low torque ripple ensures smooth motion at low speeds.
- High-Speed Capability: Rated for high RPM operation with precision bearings.
Application Scenarios:
Deployed in CNC machines, robotics, semiconductor manufacturing, and automated assembly lines.
Performance Parameters:
- Resolution: Compatible with high-resolution encoders for precise positioning.
- Thermal Performance: Optimized winding design for efficient heat dissipation.
Material Composition:
Laminated steel core, high-energy neodymium magnets, and precision-machined aluminum housing.
Structural Features:
Sealed construction with IP65 rating, featuring a standard NEMA mounting flange and single-connector option.
Working Principle:
Operates as a synchronous motor where the rotor follows the rotating magnetic field generated by the stator windings, controlled precisely by a servo drive.
Installation Requirements:
Mount securely to the machine using proper torque specifications. Ensure the shaft coupling is aligned to prevent bearing wear.
Usage Precautions:
Do not exceed the rated radial or axial shaft loads. Ensure the servo drive parameters match the motor’s nameplate data.
