Kollmorgen DRIVE AKD‑B00306‑NAAN‑000
Technical‑Specifications: ‑ Input‑Power‑Supply: 1‑phase‑or‑3‑phase‑85‑265 VAC ‑ Continuous‑Output‑Current: 3 A‑RMS ‑ Peak‑Output‑Current: 9 A‑RMS‑for‑5 seconds ‑ Continuous‑Output‑Power: 1100 W ‑ Control‑Supply‑Voltage: 24 V DC‑±20% ‑ Command‑Interface: Analog‑±10 V‑command‑input,‑pulse‑direction‑command‑input ‑ Safety‑Function: Dual‑channel‑Safe‑Torque‑Off‑STO‑SIL2‑PLd ‑ Feedback‑Interfaces: Resolver,‑EnDat2.2,‑BiSS‑C,‑HIPERFACE,‑SFD‑single‑cable‑feedback ‑ Digital‑Inputs: 3‑optically‑isolated‑digital‑inputs ‑ Digital‑Outputs: 3‑optically‑isolated‑digital‑outputs‑including‑1‑fault‑relay‑output ‑ Analog‑Input: 1‑channel‑16‑bit‑analog‑input‑±10 V ‑ Analog‑Output: 1‑channel‑16‑bit‑analog‑output‑±10 V ‑ Cooling‑Method: Natural‑convection‑heat‑dissipation‑plus‑optional‑external‑heat‑sink‑accessory ‑ Installation‑Form: DIN‑rail‑cabinet‑mounting ‑ Operating‑Ambient‑Temperature: 0 °C‑to‑+55 °C ‑ Storage‑Temperature: ‑25 °C‑to‑+70 °C ‑ Protection‑Class: IP20‑cabinet‑installation‑only ‑ Compliance‑Certification: CE,‑UL,‑RoHS,‑REACH
Functional‑Features: ‑ Compact‑hardware‑form‑factor‑reduces‑cabinet‑installation‑space‑occupation ‑ High‑bandwidth‑current‑loop‑realizes‑fast‑torque‑response‑for‑servo‑motor‑control‑task ‑ Dual‑channel‑hardware‑STO‑safety‑function‑meets‑SIL2‑PLd‑safety‑requirement‑for‑machine‑safety‑circuit‑design ‑ Supports‑multiple‑feedback‑device‑formats‑including‑SFD‑single‑cable‑feedback‑to‑reduce‑field‑wiring‑quantity ‑ Accepts‑analog‑voltage‑command‑and‑pulse‑direction‑command‑input‑to‑adapt‑traditional‑motion‑controller‑hardware‑system‑architecture ‑ Built‑in‑brake‑chopper‑circuit‑absorbs‑motor‑regenerative‑energy‑during‑deceleration‑process ‑ Comprehensive‑fault‑diagnosis‑covers‑over‑current,‑over‑voltage,‑under‑voltage,‑over‑temperature,‑feedback‑signal‑loss,‑motor‑short‑circuit‑fault‑conditions ‑ Full‑parameter‑configuration‑and‑auto‑tuning‑function‑supported‑via‑Kollmorgen‑WorkBench‑PC‑software‑tool‑through‑Ethernet‑service‑port ‑ Fault‑relay‑output‑provides‑hardware‑signal‑output‑for‑upper‑level‑machine‑control‑system‑to‑collect‑drive‑fault‑status‑information.
