Kollmorgen S30301-NA

Kollmorgen S30301-NA

Product Introduction
S30301-NA is the US order code for the SERVOSTAR 343, a 5A RMS digital servo amplifier from Kollmorgen’s SERVOSTAR 300 (S300) family. The “-NA” suffix indicates the standard version without a built-in expansion card. It belongs to the 230V to 480V voltage class (types S3xx0) and provides a balanced combination of current capacity and high-voltage operation for mid-range servo applications.

Request Quote
Category:

Description

Kollmorgen S30301-NA

Technical Specifications

  • Rated Supply Voltage: 3 × 208V to 3 × 480V AC, 50/60 Hz (−10% to +10%)
  • Rated Output Current (RMS): 5A at 3 × 230V; 4A at 3 × 400V; 3A at 3 × 480V
  • Peak Output Current: 7.5A (max. approx. 5 seconds)
  • Max DC Bus Link Voltage: 900V DC
  • Auxiliary Supply Voltage: 24V DC (−0% / +15%), electrically isolated
  • PWM Clock Frequency: 8 / 16 kHz (with 50% derating at 16 kHz)
  • Current Controller Bandwidth: > 1.2 kHz
  • Certifications: CE, UL/cUL (UL file E217428), RoHS, REACH, EAC

Functional Features

  • Fully Digital Control: Digital current controller with space vector modulation and PWM at 62.5 μs; adjustable digital speed controller; integrated position controller with 250 μs refresh time
  • Integrated STO (Safe Torque Off): Single-channel STO function certified to PLd / SIL CL 2 (PFHD 1.50E-07, TM 20 years) for functional safety restart lock
  • Multi-Feedback Support: Resolver, sine/cosine encoders, EnDat 2.1/2.2, HIPERFACE, BiSS, SSI, Hall sensors, SFD3, HIPERFACE DSL
  • Encoder Emulation: Incremental encoder output (A quad B) and SSI absolute encoder output
  • Integrated Position Controller: Stores motion tasks for autonomous execution
  • Electronic Gearing: Master-slave operation with step/direction interface
  • Onboard I/O: 2 programmable analog inputs (14/12 bit, ±10V), 4 programmable digital inputs, 2 programmable digital outputs, BTB/RTO relay output
  • Communication: RS232 and CANopen (default 500 kBaud) onboard; expansion card slot for PROFIBUS, SERCOS, DeviceNet, SynqNet, PROFINET, EtherCAT, I/O-14/08, FB-2to1, 2CAN
  • Dynamic Braking: Internal brake resistor with dynamic power distribution across multiple amplifiers on common DC bus
  • PC-Based Setup: Windows-based DRIVE.EXE setup software with wizard; alternatively, 2-key operation with 3-character LED display

Application Scenarios

  • CNC Machine Tools: Multi-axis coordinated motion control
  • Industrial Robotics: Medium-duty joint actuation
  • Packaging and Assembly Lines: High-speed material handling
  • Semiconductor Manufacturing: Precision positioning systems
  • Medical Equipment: High-precision imaging and surgical systems
  • Automated Test Equipment: Precision motion platforms

Performance Parameters

  • Continuous Current: 5A RMS at 3 × 230V; 4A RMS at 3 × 400V; 3A RMS at 3 × 480V
  • Peak Current: 7.5A
  • Rated Installed Load: 2.5 kVA at 400V continuous operation
  • Voltage Rise Speed (dU/dt): 3.0 kV/μs at 3 × 208V; 3.3 kV/μs at 3 × 230V; 5.7 kV/μs at 3 × 400V; 6.9 kV/μs at 3 × 480V
  • Overvoltage Protection Threshold: 455V at 3 × 230V; 800V at 3 × 400V; 900V at 3 × 480V
  • Residual Voltage Drop: 5V at rated current
  • Quiescent Dissipation: 12W (output stage disabled)
