Description
Kollmorgen S30601
Technical Specifications
- Product Family: SERVOSTAR 300
- Input Voltage: 208V to 480V (3-phase)
- Continuous Output Current: 6A
- Brake Circuit Threshold: S306 overvoltage F02
- Internal Brake Resistor (RBint): 66 Ohm
- Continuous Power for Internal Resistor: 50 W
- Max Brake Power (average for 1s): 0.84 kW
- Pulse Brake Power: 0.84 kW
- External Brake Resistor (RBext) Continuous Power: 0.3 kW
Functional Features
- 3-Phase Operation: Designed for 3-phase AC supply input
- Digital Servo Control: Provides precise torque, speed, and position control through digital control loops
- Integrated Brake Circuit: Internal brake resistor for regenerative energy dissipation
- External Brake Resistor Support: Compatible with external brake resistors for extended braking capacity
Application Scenarios
- Industrial Automation: Production line control, material handling, packaging machinery, robots
- Machine Tools and Cutting Equipment: CNC machine tools, laser cutting machines, plasma cutting machines
- Medical Equipment: Medical imaging equipment, surgical robots, rehabilitation equipment
- Semiconductor Manufacturing: Semiconductor cutting equipment, surface treatment equipment, packaging equipment
- Motion Simulation and Entertainment: Motion simulation devices, amusement equipment, flight simulators
Performance Parameters
- Continuous Output Current: 6A
- Input Voltage Range: 208V to 480V
- Internal Brake Resistor Value: 66 Ohm
- Continuous Resistor Power Rating: 50 W
- Max Average Brake Power (1s): 0.84 kW
- Pulse Brake Power: 0.84 kW
- External Resistor Continuous Power: 0.3 kW
Material Composition
- Metal housing with integrated electronic components including IGBT power stage, digital signal processor, and brake resistor circuit
Structural Features
- Brake Circuit Integration: Built-in brake circuit with 66 Ohm internal resistor rated at 50 W continuous
- External Resistor Connection: Provision for connecting external brake resistor
- 3-Phase Power Connectors: Input terminals for 3-phase AC supply
Working Principle
The S30601 receives 3-phase AC input power, converts it to DC bus voltage, and drives the brushless servo motor through its power stage. The cascaded digital control loops (current, velocity, position) provide precise torque, speed, and position control. The feedback device monitors the motor’s rotor position and speed, and the drive continuously adjusts the supplied current and voltage to correct any deviations from the commanded motion.
Installation Requirements
- Mounting inside a closed switchgear cabinet
- Proper EMC-compliant grounding and shielding for all cables
- External fusing required for AC supply protection
- 3-phase AC supply within the 208V to 480V range
- Suitable external brake resistors must be selected from Kollmorgen’s accessories if internal braking capacity is insufficient
Usage Notes
- Verify motor voltage and current ratings match the drive specifications
- Monitor thermal conditions during continuous operation at rated current
- Back up drive configuration parameters regularly
- Wait for DC bus voltage to drop below safe levels before handling components after power disconnection
