Description
Kollmorgen S71201-FN2
- Technical Specifications:
- Series: ServoStar 700 (S700), S712 sub-series
- Type: Digital servo amplifier
- Rated Line Power: 9 kVA (S1 operation)
- Rated Output Current: 12 Arms at 1×110 V / 1×230 V / 3×208 V / 3×230 V; 12 Arms at 3×400 V; 12 Arms at 3×480 V
- Peak Output Current: 24 Arms
- Input Voltage: 1×110 V–230 V or 3×208 V–480 V, 50/60 Hz
- DC Bus Voltage: 290–675 VDC
- Auxiliary Power: 24 VDC
- Functional Features:
- Multi-mode servo control: torque, velocity, position, and programmable positioning
- Onboard EtherCAT and CANopen fieldbus communication
- Dual-channel STO safety function (SIL2/PLd)
- Multi-feedback support: resolvers, SinCos encoders (BiSS, EnDat, HIPERFACE), incremental encoders, Hall sensors
- Integrated autotuning with oscilloscope and Bode plot display
- IEC 61131-3 macro programming (128 KB code memory, 62.5 µs cycle time)
- Internal brake resistor and EMC filter
- Dynamic braking circuit for regenerative energy dissipation
- Application Scenarios:
- High-performance CNC machinery and precision machining
- Industrial robotics and gantry systems
- Automated assembly and material handling
- Semiconductor manufacturing equipment
- Multi-axis machinery requiring 5–1
