Description
Motorola MVME147SC-1
Technical Specifications
- Microprocessor: MC68030 32-bit microprocessor.
- Main Memory: Onboard DRAM.
- Non-Volatile Storage: Battery-backed SRAM and EPROM/Flash.
- Bus Interface: IEEE 1014-1987 VMEbus.
Functional Features
- Enhanced Peripherals: May include upgraded serial controllers or additional I/O routing.
- Debug Support: 147Bug monitor.
- IndustryPack Expansion: IP module support.
- Serial Communications: Dual RS-232 ports.
Application Scenarios
Industrial automation, process control, and legacy system maintenance.
Performance Parameters
- VME Standard: A24/A32, D8/D16/D32.
- Serial Ports: Dual EIA-232.
Material Composition
Industrial-grade PCB with MC68030 and supporting logic.
Structural Characteristics
Standard 6U VME size with front-panel indicators.
Working Principle
MC68030 processor manages local bus; interface ASIC handles VME transactions.
Installation Requirements
- Standard VME chassis installation.
- Jumper configuration.
- Forced-air cooling.
Usage Precautions
- ESD protection.
- No hot-swapping.
- Battery maintenance.
