Motorola MVME162-031
Technical Specifications
- Microprocessor: 32 MHz MC68040 with FPU.
- Memory: 4MB DRAM, 512KB SRAM.
- Network: 10Base-T Ethernet with DMA.
- Serial: Dual EIA-232/422 ports.
Functional Features
- High-speed Ethernet for network-intensive applications.
- 32 MHz CPU for improved real-time response.
- VMEbus D64 block transfer support.
- IndustryPack expansion capability.
Application Scenarios
Telecommunications switching, network appliances, and industrial servers.
Performance Parameters
- CPU: 32 MHz MC68040.
- Network: 10Base-T with DMA.
- Bus: A32/D64 VMEbus.
Material Composition
Industrial-grade PCB with high-reliability components.
Structural Characteristics
6U VME board with front panel Ethernet and serial ports.
Working Principle
Processes network packets via DMA while executing control algorithms on the 32 MHz CPU.
Installation Requirements
- Connect Ethernet to shielded twisted pair cable.
- Ensure proper grounding for network isolation.
- Verify VME bus termination.
Usage Precautions
- Protect Ethernet port from ESD and surges.
- Monitor network traffic for bottlenecks.
- Keep firmware updated for security and stability.
