Motorola MVME162-211

Motorola MVME162-211

Product Introduction
The MVME162-211 operates at an increased 32 MHz clock speed, providing enhanced processing performance for industrial control applications with stringent real-time requirements.

Request Quote
Category:

Description

Motorola MVME162-211

Technical Specifications

  • Microprocessor: 32 MHz MC68040 with FPU.
  • Memory: 4MB DRAM and 512KB SRAM.
  • Interfaces: Dual serial ports and four IndustryPack ports.
  • Storage: 1MB Flash memory.

Functional Features

  • 32 MHz main frequency for faster processing.
  • VME D64 specification support.
  • Hardware watchdog timer.
  • Broad RTOS compatibility.

Application Scenarios
High-speed process control, motion control, and test and measurement.

Performance Parameters

  • Bus: A32/D64 VME master/slave.
  • Timers: Six 32-bit timers.
  • Operating Temp: 0°C to +55°C.

Material Composition
Industrial-grade PCB with three-proof coating.

Structural Characteristics
6U double-high VME module with front panel status LEDs.

Working Principle
The 32 MHz MC68040 executes control algorithms and communicates at high speed with I/O modules via the VME bus.

Installation Requirements

  • Insert into VME chassis and secure.
  • Ensure forced air cooling.
  • Connect power and ground correctly.

Usage Precautions

  • Hot-swapping is strictly prohibited.
  • Clean dust regularly.
  • Avoid strong electromagnetic interference.
