Motorola MVME162-212
Technical Specifications:
- Brand: Motorola
- Model: MVME162-212
- Processor: MC68040 Series
- Bus Architecture: VMEbus
Functional Features:
- Powerful Computing Core: Features a 32-bit enhanced microprocessor providing highly efficient real-time data processing capabilities.
- Non-Volatile Storage: Equipped with flash memory and NVRAM to ensure firmware and critical configurations are safely retained during power loss.
- Rich I/O Expansion: Supports IndustryPack modules, significantly saving VME slot space.
Application Scenarios:
Widely utilized in semiconductor manufacturing equipment, industrial automation production lines, Distributed Control Systems (DCS), and high-reliability real-time control networks.
Performance Parameters:
- Serial Communication: Multiple serial ports supporting various industrial standard protocols.
- Bus Support: Functions as a VMEbus system controller, supporting A24/A32 addressing and D8/D16/D32 data transfers.
- Operating Temperature: 0°C to +55°C (Requires forced air cooling).
Material Composition:
Constructed using industrial-grade, high flame-retardant PCB materials. Key electronic components undergo strict derating design, and the board is coated with a three-proof conformal coating.
Structural Characteristics:
Standard 6U Eurocard dimensions equipped with standard VME P1/P2 backplane connectors. The front panel features status indicator LEDs and physical RESET/ABORT buttons.
Working Principle:
Centered on the MC68040 microprocessor, it utilizes a VMEbus interface ASIC to achieve global control. Combined with hardware-level DMA and interrupt controllers, it achieves microsecond-level real-time interrupt responses.
Installation Requirements:
Must be installed in a standard 6U VME chassis using card guides. A forced air cooling system is mandatory to ensure adequate airflow across the module.
Usage Precautions:
Always wear an anti-static wrist strap before handling. Inserting or removing the module while the system is powered on is strictly prohibited. When replacing the on-board SRAM backup battery, configure the power jumpers correctly to prevent data loss.
