Motorola MVME167-04A
Technical Specifications:
- Brand: Motorola
- Model: MVME167-04A
- Product Positioning: Enhanced Flagship VME Single Board Computer
- Core Configuration: MC68040 33MHz Processor with 128MB ECC DRAM
Functional Features:
- Seamless Backward Compatibility: Fully compatible in function and pinout with the 04 model, serving as a direct drop-in upgrade.
- Anti-Interference Design: Optimized power filtering and signal shielding specifically tailored for environments with strong electromagnetic interference.
- Comprehensive Diagnostics: Inherits enhanced 166Bug diagnostic packages providing hardware-level fault isolation capabilities.
Application Scenarios:
Perfect for harsh industrial environments such as port container crane control systems, oil and gas pipeline monitoring stations, and solar power plant control cabinets.
Performance Parameters:
- Environmental Tolerance: Exceptional resistance to vibration and high temperatures, with a storage temperature range reaching -40°C to +85°C.
- System Lifespan: Significantly reduced hardware failure rates during long-term continuous operation.
Material Composition:
Utilizes the latest batch of industrial-grade components with immersion gold PCB plating to improve long-term solder joint reliability.
Structural Characteristics:
Maintains the standard 6U VME mechanical dimensions and interface layout, featuring clear model and revision silkscreen markings.
Working Principle:
Inherits the core control logic of the MVME167-04 while utilizing hardware-level reinforcement to ensure precise output of control commands under severe operating conditions.
Installation Requirements:
Follows standard VME installation norms. For extremely cold environments, allow an appropriate pre-heating period before starting the system.
Usage Precautions:
When replacing older revision boards, it is recommended to simultaneously check and update the system firmware to fully leverage the hardware advantages of the “A” revision.
