Motorola MVME172PA-644LSE
Technical Specifications
- Processor: 60 MHz MC68060 32-bit microprocessor.
- Memory: 16 MB SDRAM with ECC (Error-Correcting Code) protection.
- Storage: 2 MB Flash memory and 128 KB battery-backed SRAM.
- Communication Interfaces: Dual EIA-232-D serial ports, 10/100Mbps Ethernet, and SCSI-2 interface.
Functional Features
- High Data Integrity: Hardware-level ECC memory protection ensures data accuracy in severe environments.
- Multitasking Support: Supports real-time operating systems like VxWorks with powerful concurrent processing capabilities.
- Flexible Expansion: Supports IndustryPack (IP) modules to provide additional customized I/O capabilities.
Application Scenarios
Widely used in aerospace test benches, defense radar systems, particle accelerator control, and critical industrial process control systems.
Performance Parameters
- Processing Power: 60 MHz main frequency provides ample computing power for complex control logic.
- Bus Bandwidth: Fully utilizes VME64 bus for high-speed data throughput.
- Environmental Adaptability: Supports wide operating temperature ranges for extreme industrial conditions.
Material Composition
Constructed with multi-layer industrial-grade printed circuit boards (PCBs). Core components undergo strict screening to withstand vibration and shock.
Structural Characteristics
Standard 6U VME single-board size. The front panel features status indicator LEDs and debug interfaces, while the rear is equipped with precision VME connectors.
Working Principle
Communicates via the VME bus to execute operating systems and applications stored in Flash or SDRAM, coordinating peripheral devices to complete control tasks.
Installation Requirements
Must be installed in a standard VME chassis and backplane. Ensure connectors are fully seated and secured with screws to prevent loosening.
Usage Precautions
Always wear an anti-static wrist strap during handling. Ensure adequate chassis cooling and disconnect system power before inserting or removing the module.
