Description
Motorola MVME2432
Technical Specifications:
- Brand: Motorola
- Model: MVME2432
- Microprocessor: PowerPC 750 (PPC750) 32-bit microprocessor
- Cache: 32 KB Instruction / 32 KB Data L1 Cache, 1 MB Backside L2 Cache
- Memory: 32 MB to 512 MB onboard ECC SDRAM
- Flash Memory: 2 MB to 8 MB for boot code and configuration data
- Interfaces: Dual RS-232 serial ports, 10/100Base-T Ethernet port, VMEbus interface
Functional Features:
- Highly Customizable: Fully customizable via two PCI Mezzanine Card (PMC) sites to meet diverse application requirements.
- High Integration: Integrates the processor, memory-to-PCI bus bridge, and VME interface into a single VME slot.
- Low Power & High Performance: Leverages the low-power, high-performance PowerPC 750 microprocessor to balance energy efficiency with robust computational capabilities.
Application Scenarios:
Widely deployed in industrial automation, data acquisition and processing, telecommunications infrastructure, medical imaging equipment, and military/aerospace systems requiring high reliability.
Performance Parameters:
- Delivers superior real-time data processing capabilities.
- Supports the Peripheral Component Interconnect (PCI) bus for high-efficiency communication with onboard peripherals.
- Operating temperature: 0°C to 55°C; Storage temperature: -40°C to 85°C.
Material Composition:
Manufactured using industrial-grade electronic components and high-reliability printed circuit boards (PCBs) to ensure stable operation in harsh environments.
Structural Characteristics:
Features a standard 6U VME Single Board Computer (SBC) form factor equipped with standard VME P1/P2 connectors and a rugged front panel.
Working Principle:
Executes instructions via the PowerPC 750 core, communicates with onboard peripherals and PMC expansion cards via the internal PCI bus, and exchanges data with the system backplane through the VME interface.
Installation Requirements:
Must be inserted into a standard chassis backplane slot supporting the VME bus. Ensure connectors are perfectly aligned and securely locked before operation.
Usage Precautions:
Always implement Electrostatic Discharge (ESD) precautions before handling. Ensure adequate system cooling and airflow. Never insert or remove the module while the system is powered on.
