Description
Motorola MVME2604-4331
Technical Specifications
- Processor: 333 MHz MPC604 32-bit processor.
- On-board Storage: ROM for boot code, DRAM for program execution.
- I/O Interfaces: General-purpose digital I/O channels, optional 10BASE-T Ethernet.
- Certification Standards: Certified by CE, FCC, and other international standards.
Functional Features
- High Reliability: Utilizes industrial-grade components with a watchdog timer to prevent program anomalies or system deadlocks.
- Flexible Expansion: Supports VME bus protocol, usable as a system controller or intelligent slave device.
- Wide Temperature Adaptation: Designed for wide-temperature environments, adapting to extreme industrial sites.
Application Scenarios
Applicable to heavy industries such as metallurgy, coal mining, petrochemicals, electric power, and water conservancy, as well as data processing in military electronic systems.
Performance Parameters
- Address Space: Supports A16/A24/A32 addressing.
- Data Width: Supports D16/D32 data transfer.
Material Composition
Multi-layer PCB design. Key high-power-density integrated circuits are thermally optimized to ensure case temperatures remain within specifications.
Structural Characteristics
Standard 6U Eurocard dimensions with standard VME P1/P2 connectors.
Operating Principle
Scheduled by a Real-Time Operating System (RTOS), it executes logical control, data communication, and management tasks, collaborating with other I/O modules via the VME bus.
Installation Requirements
Must be securely locked in the VME chassis using matching guide rails and fixing screws to prevent poor contact due to vibration.
Usage Precautions
Strictly prohibited to supply power exceeding the rated voltage. When used in flammable and explosive environments, ensure the overall system possesses corresponding explosion-proof certification.
