Description
Motorola MVME2700-233
Technical Specifications
- Processor: 233 MHz MPC750 PowerPC.
- Memory: 16 MB – 256 MB ECC DRAM.
- Storage: 8 MB Flash + 1 MB socketed Flash.
- Cache: 32KB/32KB L1, 1MB L2.
Functional Features
- Full System Controller: VME arbitration, interrupt handling, DMA.
- Multi-Port Serial: Zilog Z85230 ESCC + PC87308 SIO.
- Graphics & Peripherals: PS/2 keyboard/mouse, floppy, parallel.
- Flexible Memory Base: DRAM base address remappable via firmware/software.
Application Scenarios
Automated assembly lines, smart grid monitoring, railway signaling, marine exploration, high-reliability server clusters.
Performance Parameters
- Memory Interleaving: Dual-path interleaved access for higher throughput.
- PCI Spec: 32-bit address / 64-bit data local PCI bus.
- Ethernet: AUI or 10Base-T/100Base-TX auto-negotiation.
Material Composition
Multi-layer HDI PCB with BGA processor for optimal thermal performance and mechanical vibration resistance.
