Motorola MVME7100-0173
Technical Specifications
- Processor: 1.3 GHz MPC8641D dual-core PowerPC e600.
- Memory: 2 GB DDR2 ECC.
- Storage: 8 GB NAND Flash, 128 MB NOR Flash.
- Network: Four Gigabit Ethernet ports.
Functional Features
- IEEE Compliance: Meets IEEE mechanical and electrical standards.
- High-Speed I/O: PCIe, PMC-X, and 2eSST VME.
- Real-Time Capable: Optimized for deterministic real-time operating systems.
Application Scenarios
Defense electronics, industrial automation, telecommunications, and test and measurement equipment.
Performance Parameters
- Power: Typical 45W, Maximum 60W @ +5V.
- Bandwidth: Balanced processor, memory, and I/O subsystem performance.
Material Composition
High-reliability components with industrial temperature ratings and robust PCB construction.
Structural Characteristics
- Form Factor: 6U VME IEEE standard.
- Cooling: Forced-air cooling with optimized airflow path.
- Panel I/O: Front-accessible Ethernet, serial, and USB ports.
Working Principle
The integrated SoC architecture provides balanced performance across all subsystems. The VME bridge enables seamless integration with existing backplane infrastructure while local PCIe and PMC interfaces support modern high-speed peripherals.
Installation Requirements
- Install in IEEE-compliant VME chassis.
- Ensure proper power and cooling.
- Configure system parameters via firmware.
Usage Precautions
- Follow ESD handling procedures.
- Maintain operating environment within specifications.
- Regularly update firmware for security and performance.
