Description
NORISYS 4UNIO 4AI4AO
Technical Specifications:
- Brand: NORISYS
- Model: 4UNIO 4AI4AO
- Product Type: Universal I/O Module
- Channel Configuration: 4 Analog Inputs (AI), 4 Analog Outputs (AO)
Functional Features:
- Universal Channel Design: Channels can be software-configured as voltage, current, or digital signals, providing maximum engineering flexibility.
- High Resolution: Offers high-bit A/D and D/A conversion for precise process control and monitoring.
- Electrical Isolation: Provides channel-to-channel and channel-to-bus galvanic isolation.
Application Scenarios:
Ideal for process control, HVAC systems, water treatment, and test benches requiring mixed-signal I/O in a compact footprint.
Performance Parameters:
- Accuracy: High-precision signal conditioning with minimal offset and gain error.
- Response Time: Fast update rates for dynamic process control.
Material Composition:
Industrial-grade electronic components with conformal coating protection in a durable plastic housing.
Structural Features:
Compact DIN rail mountable design with spring-clamp or screw terminals for rapid, tool-less wiring. Features per-channel status LEDs.
Working Principle:
Converts physical analog signals (e.g., 0-10V, 4-20mA) into digital values for the PLC, and converts digital control values back into precise analog outputs for actuators.
Installation Requirements:
Mount on a standard DIN rail. Use shielded twisted-pair cables for analog signals and ground the shield at the panel side only.
Usage Precautions:
Configure the channel type in the software before applying field power. Ensure the connected load impedance matches the output specifications.
