SEW DRL180LC4/FI/TF/EG7S/V

SEW DRL180LC4/FI/TF/EG7S/V

Product Introduction:
The DRL180LC4/FI/TF/EG7S/V is an asynchronous servo motor from SEW-EURODRIVE’s DRL series, designed for high-dynamic positioning and speed control in demanding industrial applications. The “DRL” prefix identifies the asynchronous servo motor series. The “180” denotes the frame size (180 mm center height), indicating a larger and more powerful unit compared to the DRL160 variant. The “LC” indicates the mounting position (LC position). The “4” specifies a 4-pole motor configuration. The “/FI” designates the output configuration (flange/interface type). The “/TF” indicates integrated thermal protection via PTC thermistors embedded in the stator winding. The “/EG7S” specifies an additional external sinusoidal encoder for precise speed and position feedback. The “/V” denotes a forced cooling fan for enhanced thermal management under continuous high-load operation.

Request Quote
Category:

Description

SEW DRL180LC4/FI/TF/EG7S/V

Technical Specifications:

  • Brand: SEW-EURODRIVE
  • Series: DRL (Asynchronous Servo Motor)
  • Frame Size: 180 (center height 180 mm)
  • Mounting Position: LC
  • Poles: 4-pole
  • Supply Voltage: 3 × 380–500 VAC
  • Insulation Class: F (155°C)
  • Protection Class: IP54 / IP55
  • Operating Mode: S1 continuous duty
  • Thermal Protection: PTC thermistors (/TF)
  • Encoder: External sinusoidal encoder (/EG7S)
  • Cooling: Forced ventilation fan (/V)
  • Output Configuration: FI type

Functional Features:

  • High Dynamic Overload Capability: Supports dynamic overload currents up to 350% of rated current for short durations
  • Two Dynamic Power Packages: Power Package 1 (approximately 200 Mdyn/MN for standard gear shaft ends) and Power Package 2 (approximately 300 Mdyn/MN for reinforced gear shaft ends)
  • Four Speed Levels: 1200, 1700, 2100, and 3000 rpm
  • High-Resolution Sinusoidal Encoder: The /EG7S encoder provides precise rotor position feedback for closed-loop vector control
  • Integrated Thermal Protection: PTC thermistors (/TF) for reliable overtemperature monitoring
  • Forced Cooling Fan: The /V fan ensures consistent thermal performance at low speeds and high continuous loads
  • Modular System Compatibility: Compatible with SEW’s DR series modular motor system for combination with servo gearboxes, brakes, backstops, and other accessories
  • High External Inertia Control: Optimized for controlling high external moments of inertia relative to the motor shaft

Application Scenarios:

  • Gantry picking robots
  • Traveling axes in palletizing machines
  • Winding drives and cutting drums
  • Gantry lifting axes
  • Conveyor applications with precise speed regulation
  • Machine tool main spindle and feed drives
  • Printing press drives
  • Heavy-duty automated material handling

Performance Parameters:

  • Torque Range: 5 Nm to 200 Nm (across the DRL series)
  • Nominal Torque: Higher than DRL160 variant due to larger frame size
  • Dynamic Overload: Up to 3 to 4 times rated torque
  • Speed Levels: 1200 / 1700 / 2100 / 3000 rpm
  • Inertia Range: 4.9 to 4330 kg·cm² (series range)
  • Continuous Temperature Rise: Not exceeding 75K under continuous high-load operation
  • Speed Control Quality: High precision with sinusoidal encoder feedback

Material Composition:

  • Cast iron or high-strength aluminum housing
  • Precision-laminated silicon steel rotor and stator cores
  • Copper windings with Class F insulation system
  • High-grade rolling element bearings
  • Steel output shaft with precision machining
  • Powder-coated corrosion-resistant exterior finish

Structural Features:

  • Robust frame construction with optimized thermal dissipation
  • LC mounting position configuration
  • FI-type output interface
  • Integrated PTC thermal sensors in stator winding
  • External encoder mounting adapter (/EG7S) with adapter ring
  • Forced cooling fan assembly (/V) with fan guard
  • Terminal box for power and signal connections
  • Nameplate with complete technical specifications

Working Principle:
The DRL180LC4 operates as a field-oriented controlled asynchronous motor. The inverter generates a rotating magnetic field in the stator, inducing rotor currents that produce electromagnetic torque. The /EG7S sinusoidal encoder continuously monitors rotor position and speed, feeding this data back to the inverter for real-time flux and torque decoupling. The forced cooling fan (/V) maintains optimal winding temperature during continuous high-load operation. The PTC thermistors (/TF) provide an additional safety layer by triggering a shutdown if the winding temperature exceeds safe limits.

Installation Requirements:

  • Mount on a rigid foundation with proper alignment to the driven equipment
  • Ensure the forced cooling fan has unobstructed airflow on all sides
  • Connect the encoder cable to the corresponding inverter encoder input
  • Connect PTC thermistor leads to the inverter’s thermal protection input
  • Use shielded motor cables with 360° shield grounding
  • Verify correct phase sequence (U-V-W) before startup
  • Perform motor initialization and auto-tuning via the inverter software
  • Ensure adequate clearance for the LC mounting position
