Triconex 7400166-390
Triconex 7400166-390 - Image 2

Triconex 7400166-390

Product Introduction: The Triconex 7400166-390 is a terminal panel designed for Triconex digital output module 2652-5. It provides the field-side termination points for wiring actuators, indicators, and other devices, and interfaces with the 2652-5 module via internal connections. The terminal panel is part of the Triconex Trident/Tricon series, used in safety instrumented systems where reliable termination and easy maintenance are required.

Request Quote
Category: SKU: Triconex 7400166-390

Description

Triconex 7400166-390

Technical Specifications:

  • Type: Terminal panel (termination board)
  • Associated module: Triconex 2652-5 digital output module
  • Number of termination points: Matches the channel count of 2652-5
  • Voltage rating: Compatible with 24 V DC (per associated module ratings)
  • Current rating: As per field device and module specifications (typically up to 2 A per point)
  • Operating temperature: 0 °C to 60 °C (per Tricon system environmental specs)
  • Protection rating: IP20 (panel-mounted in enclosure)
  • Terminals: Pluggable or screw terminals for secure wiring

Functional Features:

  • Provides organized termination for field wiring
  • Supports hot-swap of the associated I/O module when used in redundant configurations
  • Designed for easy identification and labeling of circuits
  • High reliability with industrial-grade components

Application Scenarios:

  • Termination for digital outputs in Triconex safety systems
  • Used in ESD, F&G, BMS, HIPPS applications
  • Suitable for oil and gas, chemical, power generation, and other safety-critical industries

Performance Parameters:

  • Ensures secure and low-resistance connections
  • Supports fast response times consistent with digital output modules
  • Provides reliable operation under industrial environmental conditions

Material and Structural Characteristics:

  • Base material: Fiberglass-reinforced plastic or metal
  • Terminals: Plated metal for corrosion resistance
  • Markings: Clear labeling for circuit identification
  • Mounting: Designed for panel installation in Triconex cabinets

Working Principle: Field devices are wired to the terminal panel. The panel routes signals to the 2652-5 module through internal connectors. In redundant configurations, the panel supports both active and standby modules, ensuring continuous operation. Installation Requirements:

  • Mount in a Triconex cabinet with proper clearance for wiring
  • Connect field wires to the terminals following the wiring diagram
  • Ensure proper grounding of the panel
  • Verify compatibility with the 2652-5 module and system configuration

Usage Notes:

  • Follow torque specifications for terminal screws
  • Periodically check for loose connections or corrosion
  • Use only Triconex-specified terminal panels and accessories
  • Maintain environmental conditions within specified limits
