Woodward 3522-1005
Technical Specifications
- Brand: Woodward
- Model: 3522-1005
- Power Supply: 24V DC ±10%
- Signal I/O: Supports multiple analog and digital input/output signal types (e.g., 4-20mA, 0-10V)
- Communication: Compatible with upper computers and control systems via standard industrial protocols
Functional Features
- Closed-Loop PID Control: Utilizes Proportional-Integral-Derivative (PID) algorithms to automatically eliminate deviations between actual and set rotational speeds.
- Multi-Mode Switching: Seamlessly transitions between manual/auto modes and speed/load control modes depending on grid connection status.
- Adaptive Parameter Tuning: Automatically optimizes PID parameters based on load changes to prevent over-adjustment or slow responses.
- Advanced Protection: Features anti-integral saturation design and hardware-level watchdog timers to ensure system stability.
Application Scenarios
Widely applied in industrial power generation, including gas turbines, diesel generator sets, and steam turbines, particularly in environments requiring precise speed regulation and load sharing.
Performance Parameters
- Control Accuracy: High-precision regulation of rotational speed and actuator positioning.
- Reliability: Equipped with built-in hardware diagnostics that trigger alarms and record fault codes for signal disconnection or out-of-range fluctuations.
- Output Driving: Supports analog outputs (4-20mA) for electro-hydraulic servo valves and digital relay outputs for safety interlocks.
Material Composition
Constructed using industrial-grade electronic components, high-quality printed circuit boards (PCBs), and robust housing materials designed to withstand harsh industrial environments.
Structural Characteristics
Features a compact, modular design with standardized terminal blocks for signal wiring, DIN-rail or panel mounting capabilities, and front-panel status indicator LEDs.
Working Principle
The controller continuously acquires signals from magnetoelectric speed sensors and analog transmitters. After filtering and A/D conversion, the microprocessor executes PID algorithms to calculate the required output. This output drives electro-hydraulic or electric actuators to adjust fuel valves or steam valves, maintaining the desired speed or load.
Installation Requirements
- Mount the controller in a well-ventilated enclosure with adequate clearance for heat dissipation.
- Use shielded cables for all analog and speed sensor inputs to prevent electromagnetic interference (EMI).
- Torque all terminal screws to the manufacturer’s specified values to ensure secure connections.
Usage Precautions
- Always disconnect power before wiring or modifying connections.
- Verify that the power supply voltage is within the specified 24V DC ±10% range.
- Perform regular calibration of speed sensors and output signals to maintain control accuracy.
