ABB CP650
- Technical Specifications:
- Display: 10.4″ TFT-LCD, 800 × 600 (SVGA), 65 K colors
- Touch Screen: 4-wire resistive, single-touch
- Processor: ARM Cortex-A8, 1 GHz
- Memory: 256 MB RAM, 256 MB Flash (project up to ~60 MB)
- Slot: SD card slot for data logging / project backup
- Interfaces: 2 × Ethernet 10/100 Mbps, 1 × RS-232/RS-485 (configurable), 2 × USB 2.0 host
- Power Supply: 24 V DC (18–30 V DC), typ. 12 W
- Brightness: 300 cd/m², LED backlight (50 000 h typical)
- Front Protection: IP65 (front), IP20 (rear)
- Operating Temp.: –25 °C to +70 °C
- Cutout: 276 × 221 mm; Panel depth: 56 mm
- Weight: ≈2.1 kg
- Functional Features:
- Vector graphics with alpha-blending, SVG support
- Multi-language project (Unicode / Far-East fonts supported)
- Built-in alarm list, event log, trend (historical & real-time)
- Recipe management, scheduler, email notification
- Multiple simultaneous communication drivers (Modbus TCP/RTU, ABB AC500, Ethernet/IP, etc.)
- VNC server for remote viewing
- Application Scenarios:
- Packaging / bottling lines — machine status & batch recipe HMI
- Water/wastewater pump station local operator panel
- Material handling conveyor system control station
- Small process skid local interface in pharma / F&B
- Material & Structure:
- Front bezel: Anodized aluminum
- Rear housing: Die-cast aluminum / flame-retardant ABS
- Touch overlay: Glass with polyester hard coat
- Mounting: Panel clamp with screws, landscape or portrait capable
- Working Principle:
The HMI executes a compiled PB610 project stored in Flash. It cyclically exchanges process data (tags) with the connected controller via selected communication driver(s). Operator inputs (button presses, setpoint changes) are written to controller registers; process values read from the controller update screen objects (numeric displays, bar graphs, animated symbols) at the configured refresh rate.
- Installation Requirements:
- Cut rectangular opening per dimensional drawing (276 × 221 mm)
- Secure with four mounting clamps; ensure uniform gasket compression for IP65
- Connect 24 V DC supply (observe polarity), shield and ground signal cables separately
- Download PB610 project via Ethernet or USB before commissioning
- Precautions:
- Do NOT clean front with abrasive or solvent-based cleaners — use soft cloth with mild detergent
- Avoid sharp objects on resistive touchscreen
- Ensure proper earth grounding of panel and cabinet to prevent ESD damage
- Backlight dimming can be configured to extend LED lifetime in 24/7 applications
