Description
Bently 330130‑000‑00‑05
Technical Specifications: Effective Cable Length: 0 m (direct‑connect jumper assembly) Nominal Impedance: 75 Ω Operating Temperature Range: ‑51 °C ~ +177 °C Connector Type: Click‑Loc gold‑plated explosion‑proof coaxial connector Agency Certifications: ATEX, IECEx, CSA Maximum Tensile Load: 330 N Net Weight: 75 g Compatible System: 3300 XL 8 mm proximity transducer system
Functional Features: Explosion‑proof certification permits deployment inside gas‑hazardous classified zones. Click‑Loc self‑locking connector resists vibration‑caused disconnection. Full‑coaxial shielding rejects EMI/RFI noise. CableLoc strain‑relief structure protects connector root from tensile stress. Factory electrical matching removes requirement for field calibration. Sealed connector structure satisfies hazardous‑area isolation requirements.
Application Scenarios: Direct short‑range connection between proximity probe and Proximitor sensor inside refinery and chemical‑plant hazardous areas. Used for machinery monitoring points where Proximitor is arranged adjacent to machine‑mounted probe.
Performance Parameters: Center Conductor DC Resistance: Negligible jumper‑level resistance Shield Conductor DC Resistance: Negligible jumper‑level resistance Connector Mating Cycle Life: More than 1000 insert‑extract cycles Maximum Operating Relative Humidity: 93 % non‑condensing
Material Composition: Connector Insulation: FEP fluoropolymer Signal Conductor: High‑purity silver‑plated copper Connector Body: Gold‑plated brass alloy Explosion‑proof Sealing Gasket: Fluororubber
Structural Features: Dual‑ended Click‑Loc self‑locking explosion‑proof connectors assembled on short jumper body. Built‑in CableLoc strain‑relief transition sections at both terminals. Hermetic sealing structure for hazardous‑area isolation. No intermediate cable‑splice points.
Working Principle: Passive zero‑length signal jumper. It transfers eddy‑current‑related high‑frequency impedance‑variation signals without signal attenuation or phase shift. Sealing construction satisfies explosion‑proof isolation requirement for hazardous‑zone signal interconnection.
Installation Requirements: Make sure connectors fully click‑locked after mating. Perform single‑end shielding‑layer grounding, forbid double‑end grounding. Comply with local hazardous‑area installation codes. Avoid pulling force acting directly on connector body. Keep connectors away from oil‑water immersion.
Usage Notes: Probe integral‑cable length must match Proximitor calibrated total‑system length. Do not replace original certified connectors with non‑certified accessories in hazardous‑area environment. Operate only on connector housing during mating‑unmating operations. Inspect sealing gasket condition periodically.
