Bently 3500/61-01-01
Technical Specifications
- Module Type: 4-Channel Vibration Monitor Module
- Configuration Code: 01-01 (Standard Configuration)
- Channel Count: 4 independent channels
- Slot Placement: Any available monitor slot
Functional Features
- Industry Standard: The baseline vibration monitor for the 3500 platform, widely supported and documented.
- Plug-and-Play: Fully compatible with 3500 Rack Configuration Software without requiring special hardware jumpers.
- Continuous Monitoring: Continuously compares current machine vibration values against user-programmable alert and danger setpoints.
Application Scenarios
Standard deployment for any 3500 system requiring continuous vibration monitoring for rotating machinery.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity Tolerance: 95% non-condensing
Material Composition
Industrial-grade electronic components with environmental protection coatings.
Structural Characteristics
Full-height module with front-panel LEDs indicating the status of each channel and overall module health.
Working Principle
Processes signals from velocity or acceleration sensors to generate vibration measurements, triggering alarms when configured thresholds are exceeded.
Installation Requirements
Install in any available monitor slot. Ensure proper sensor gap and cabling.
Usage Notes
Configure the correct sensor type, sensitivity, and alarm setpoints via the 3500 Rack Configuration Software.
