Description
ELAU SM100-40-050-P0-45-S1-B1
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SM100-40-050-P0-45-S1-B1
- Series: SM100
- Flange Size: 100 mm
- Brake: Integrated Holding Brake (B1)
Functional Features:
- Holding Brake: Automatically engages when power is removed to hold the load in position.
- High Precision: Supports high-precision motion control.
- Robust Design: IP65 protection for harsh environments.
- Modular Integration: Compatible with ELAU PacDrive systems.
Application Scenarios:
- Vertical axes (Z-axis) in robotics.
- Lifting and hoisting applications.
- Packaging machinery where load holding is critical.
Performance Parameters:
- Rated Speed: 4000 RPM.
- Rated Torque: 5.0 Nm.
- Brake Torque: Sufficient to hold the rated load (verify specific value in manual).
Material Composition:
- Industrial grade housing.
- Electromagnetic brake components.
Structural Features:
- Flange mounting with brake housing.
- Standard electrical interfaces.
Working Principle:
Operates as a standard AC servo motor. The integrated brake is an electromagnetic device that releases when voltage is applied and engages via spring force when power is cut, securing the shaft position.
Installation Requirements:
- Ensure the brake control circuit is connected to the drive’s brake output.
- Mount securely to handle the additional weight of the brake.
- Verify the brake release voltage.
Usage Notes:
- The brake is a holding brake, not a dynamic braking device; do not use it to stop motion at high speeds.
- Check the brake gap and wear periodically.
- Ensure proper ventilation as the brake generates heat.
