Product Introduction: The ELAU SM100-50-030-P0-45-S1-B1 is a high-speed servo motor variant from the SM100 series. The “50” indicates a higher speed rating (5000 RPM), making it suitable for applications requiring rapid motion.

Request Quote
Category:

Description

ELAU SM100-50-030-P0-45-S1-B1

Technical Specifications:

  • Brand: ELAU (Schneider Electric)
  • Model: SM100-50-030-P0-45-S1-B1
  • Series: SM100
  • Flange Size: 100 mm
  • Rated Speed: 5000 RPM
  • Rated Torque: 3.0 Nm

Functional Features:

  • High Speed: Optimized for applications requiring speeds up to 5000 RPM.
  • Holding Brake: Integrated brake (B1) for vertical axis safety.
  • High Dynamic Response: Low inertia design for fast acceleration.
  • Precision Control: High-resolution encoder feedback.

Application Scenarios:

  • High-speed packaging (labeling, cutting).
  • Robotics (fast pick and place).
  • Spindle drives in light machining.

Performance Parameters:

  • Power Rating: Approx. 1.5 kW (estimated based on torque/speed).
  • Control Modes: Position, Speed, Torque.
  • Overload Capacity: High overload capability for short durations.

Material Composition:

  • High-strength aluminum housing.
  • NdFeB magnets.

Structural Features:

  • Compact design with integrated brake.
  • IP65 protection.

Working Principle:
The motor converts electrical energy into high-speed mechanical rotation. The control system adjusts the frequency and voltage of the supply to maintain precise speed and position control, while the brake ensures safety during power loss.

Installation Requirements:

  • Ensure the mechanical system is balanced for high-speed operation.
  • Connect the brake control wires correctly.
  • Use high-quality shielded cables.

Usage Notes:

  • Verify the maximum speed rating of the connected drive.
  • Monitor bearing temperature during high-speed operation.
  • Ensure the brake is released before attempting to move the axis.
