Product Introduction
The FBC01 P0951CE-A is a specialized Fieldbus Component or accessory within the Foxboro I/A Series system. The “FBC01” designation indicates its role in fieldbus infrastructure, providing critical support for communication networks or physical fieldbus connections.

Request Quote
Category:

Description

Foxboro FBC01 P0951CE-A

Technical Specifications

  • Hardware Code: P0951CE-A
  • Product Type: FBC01 (Fieldbus Component)
  • Integration: Fieldbus network or Backplane integration
  • Communication: Module Fieldbus or External Fieldbus

Key Features

  • Dedicated Fieldbus Function: Engineered to fulfill a specific, indispensable role within the fieldbus architecture.
  • High Reliability: Built with redundant-ready architecture to maintain network availability during hardware faults.
  • Hot-Swappable Maintenance: Supports online replacement to minimize production downtime.
  • Integrated Diagnostics: Provides real-time status monitoring to simplify troubleshooting and routine inspections.

Application Scenarios
Deployed in critical process automation environments, including refining, petrochemicals, and power generation, as an essential building block of the fieldbus communication infrastructure.

Performance Parameters

  • Operating Temperature: 0°C to 60°C
  • Protection Rating: IP20
  • Power Supply: 24 VDC via backplane or dedicated supply

Material Composition
Housed in a flame-retardant, high-strength industrial enclosure with conformal-coated internal electronics to resist corrosion, moisture, and harsh atmospheric conditions.

Structural Characteristics
Standard industrial form factor designed for seamless integration with 200 Series baseplates or system racks. Features clear status indicators and precision rear connectors.

Operating Principle
Acquires power and establishes communication via the system backplane or fieldbus. It executes its designated fieldbus function and exchanges data with adjacent controllers or network components.

Installation Requirements
Install in a clean, well-ventilated control cabinet. Ensure adequate front clearance for hot-swapping and maintain a low-impedance protective earth ground.

Usage Precautions
Never force-insert non-hot-swappable components while energized. Verify that the correct Terminal Assembly (TA) or mating connector is used. Always observe standard ESD precautions during handling.
