Description
Foxboro FBM15 PM400YR
Technical Specifications
- Module: FBM15.
- Part Number: PM400YR.
- Function: Signal Conditioning and I/O.
- Bus: 2 Mbps Redundant.
Functional Features
- Precise Identification: Ensures exact matching for spare parts.
- Robust Design: Built for continuous industrial operation.
- Smart Diagnostics: Detects wire breaks and shorts.
Application Scenarios
Oil and gas, petrochemical, and power generation process control.
Performance Parameters
- Accuracy: ±0.1% F.S. or better.
- Response Time: Configurable filtering.
Material Composition
Die-cast aluminum or high-strength plastic housing. Conformal-coated PCBs.
Structural Characteristics
Compact long-strip design. Side-mounted bus connectors. Top/bottom field wiring.
Working Principle
Internal microprocessor converts signals, packages data, and communicates via the redundant fieldbus.
Installation Requirements
Use dedicated terminal assemblies. Daisy-chain bus wiring; no star branching. Install terminators.
Usage Precautions
Distinguish signal ground from shield ground. Disable node in software before replacement.
