Description
Foxboro FBM16 PM400YS
Technical Specifications
- Product Type: Fieldbus Module (FBM16).
- Commercial Part Number: PM400YS.
- System Compatibility: Foxboro I/A Series / Compact 200 Series.
- Bus Interface: 2 Mbps Redundant HDLC Fieldbus.
- Power Supply: 24 VDC backplane powered.
Functional Features
- Signal Conditioning: High-precision analog-to-digital and digital-to-analog conversion for accurate process control.
- Galvanic Isolation: Channel-to-channel and channel-to-bus isolation to prevent ground loops and protect against field surges.
- Diagnostic Capabilities: Real-time reporting of wire breaks, short circuits, and module health.
- Hot-Swap Support: Designed for module replacement without shutting down the process (system dependent).
Application Scenarios
Widely used in process control panels for connecting transmitters, valves, switches, and analyzers in oil and gas, chemical, power, and water treatment facilities.
Performance Parameters
- Accuracy: Typically ±0.1% of span for analog signals.
- Response Time: Configurable digital filtering, <10 ms fastest.
- Environmental Rating: G3 Harsh Environment certified.
Material Composition
Industrial-grade PCB with conformal coating. Durable housing with high-quality, gold or tin-plated terminal blocks.
Structural Characteristics
Standard FBM form factor with front-panel LEDs for channel status and module health. Clear silkscreen labeling for wiring identification.
Working Principle
Converts analog field signals to digital data for the fieldbus and converts digital control outputs to analog signals for field actuators, while providing isolation and power management.
Installation Requirements
Mount on a compatible baseplate or DIN rail. Use shielded twisted-pair cabling for field connections. Ensure proper grounding of shields at the cabinet end.
Usage Precautions
Verify signal type and range configuration in the control software before connecting field devices. Do not exceed the maximum load or voltage ratings for output channels.
