Description
Foxboro FBM203C P0922UD
Technical Specifications
- Module Type: RTD Input Module
- Input Capacity: 8 isolated channels
- Sensor Type: Copper RTD
- Bus Interface: Foxboro Module Fieldbus
Functional Features
- Copper RTD Optimization: Specifically calibrated for Copper RTD characteristics.
- Channel Isolation: Prevents ground loop errors.
- High-Precision Conversion: Ensures accurate low-temperature measurement.
- Hot-Swappable Design: Enables online maintenance.
Application Scenarios
Deployed in motor winding temperature monitoring, transformer temperature sensing, and low-temperature process control.
Performance Parameters
- Operating Temperature: -40℃ to +70℃
- Power Dissipation: 3W maximum
- Ingress Protection: IP20
Material Composition
Features precision analog circuitry with conformal-coated PCBs.
Structural Characteristics
Standard 200 Series FBM form factor. Connects via a dedicated TA.
Working Principle
Copper RTD resistance is measured, converted to temperature, and transmitted over the Module Fieldbus.
Installation Requirements
Install on a 200 Series baseplate. Use proper RTD wiring configuration for lead compensation.
Usage Precautions
Verify Copper RTD configuration in software. Ensure correct lead wire connections. No calibration required.
