Foxboro FBM218 P0922VW
Technical Specifications
- Output Type: 0-20mA with HART Digital Communication
- Output Channels: 8 redundant channels
- Communication Protocol: Redundant 2 Mbps Module Fieldbus
- Hardware Code: P0922VW
Key Features
- Hardware-Level Redundancy: Guarantees continuous actuator control by providing redundant output paths.
- Smart Actuator Communication: Supports HART protocol for remote diagnostics and parameter configuration.
- Seamless Failover: Ensures uninterrupted control signal delivery upon primary channel failure.
- Integrated Diagnostics: Provides comprehensive redundancy status and output channel health monitoring.
Application Scenarios
Critical for safety systems and high-value process control in petrochemicals, power generation, and offshore platforms where actuator reliability is non-negotiable.
Performance Parameters
- Operating Temperature: 0°C to 60°C
- Storage Temperature: -40°C to 85°C
- Power Supply: 24 VDC redundant backplane supply
Material Composition
Features a rugged industrial enclosure with conformal-coated internal circuitry for maximum environmental protection.
Structural Characteristics
Standard 200 Series FBM single-width design. Connects to the backplane via a secure rear interface and utilizes a designated Terminal Assembly for redundant field wiring.
Operating Principle
Generates a precise 0-20mA analog control signal with superimposed HART digital communication. In redundant mode, the system continuously validates the primary output and seamlessly transitions to the backup output if a fault is detected.
Installation Requirements
Install on a Foxboro 200 Series baseplate. Redundant configuration must be strictly defined in the system software. Ensure redundant field wiring is identical and properly routed.
Usage Precautions
Verify that the external load impedance and voltage are within the module’s rated specifications. Ensure HART addresses are uniquely configured and that redundancy logic is correctly implemented.
