Foxboro FBM24 P0900HT
Technical Specifications
- Module Type: Combination Digital I/O Module
- Input Capacity: 8 channels of contact/DC voltage inputs
- Output Capacity: 8 channels of contact outputs
- Bus Interface: Foxboro Module Fieldbus
Functional Features
- Integrated I/O Functionality: Combines DI and DO in one module to save baseplate space and reduce wiring.
- Isolated Relay Outputs: Provides galvanically isolated contacts for safe switching of external loads.
- Hot-Swappable Capability: Supports online maintenance for maximum process uptime.
- Real-Time Diagnostics: Reports input states and output relay status to the controller.
Application Scenarios
Perfect for motor control, solenoid actuation, batch sequencing, and any discrete process where an output command requires a corresponding input confirmation.
Performance Parameters
- Operating Temperature: 0℃ to 60℃
- Ingress Protection: IP20
- Power Requirements: Backplane powered, 24 VDC nominal via 200 Series baseplate
Material Composition
Features industrial-grade housing with conformal-coated electronics and high-endurance relay components.
Structural Characteristics
Standard 200 Series FBM form factor. Utilizes a specialized TA that clearly separates input and output terminal blocks.
Working Principle
The module independently processes input signals and output commands. Inputs are conditioned and isolated, while outputs are driven by relay coils controlled by the backplane bus.
Installation Requirements
Install on a 200 Series baseplate. Ensure adequate spacing between input and output wiring at the TA to prevent induced noise.
Usage Precautions
Verify relay output load ratings before connection. Never wire AC and DC signals to the same TA without proper isolation. Always follow lockout/tagout procedures during maintenance.
