Description
Foxboro FBM242 P0916TA
Technical Specifications
- Hardware Code: P0916TA
- Connection Type: Compression Terminal
- Compatibility: Specific FBM242 / 200 Series Modules
- Protection Rating: IP20
Key Features
- High-Vibration Resistance: Utilizes compression terminal technology to ensure connections remain secure in high-vibration industrial environments.
- Standardized Wiring: Enforces factory-standard wiring practices, simplifying installation and future maintenance.
- Safe Isolation: Provides physical isolation between field wiring and the low-voltage backplane circuitry.
- Hot-Swap Compatible: Designed to work seamlessly with hot-swappable FBM modules.
Application Scenarios
Deployed across all process industries utilizing the Foxboro I/A Series DCS as the standard physical interface for field instrument connections.
Performance Parameters
- Operating Temperature: 0°C to 60°C
- Wiring Specification: Supports standard industrial shielded twisted-pair cables
Material Composition
Constructed with high-strength, flame-retardant industrial-grade plastic bases and high-conductivity copper alloy crimp contacts to ensure low contact resistance and corrosion resistance over time.
Structural Characteristics
Compact modular form factor that perfectly mates with the corresponding FBM module. Features clear channel identifiers and wiring孔位 on the front, with precision pins on the rear for direct backplane对接.
Operating Principle
Field instrument signal and power wires are terminated into the P0916TA. The TA internally distributes power and signals, transmitting them losslessly to the FBM module via the rear connector for processing.
