Product Introduction: FBMSVH is a control and redundancy module associated with the Foxboro I/A Series and Foxboro PAC (Programmable Automation Controller) systems. It integrates with Foxboro’s automation platform to provide high availability, redundancy, and robust I/O processing for continuous process control applications. The module supports redundant processor operation and provides comprehensive diagnostics, facilitating uninterrupted control in harsh industrial environments.

Request Quote
Category: SKU: Foxboro FBMSVH

Description

Foxboro FBMSVH Technical Specifications:

  • Functionality: Core control/processor module in I/A Series/PAC systems with redundancy support
  • Processor: 32-bit industrial-grade RISC; 0.1 µs/Boolean, 0.5 µs/floating-point instruction speed
  • Memory: Program memory 8 MB, data memory 4 MB
  • Communication Interfaces: Ethernet 10/100BaseTX for control network; supports Modbus TCP/IP, Ethernet/IP, ControlNet (variants)
  • Environment: Operating temperature 0 °C to 60 °C; storage –40 °C to +85 °C; G3-class harsh environment capability
  • Protection: IP20 (in cabinet); robust mechanical design for shock/vibration
  • Power: 24 V DC with redundant power options
  • I/O Capacity: Supports up to 32 200-series FBM natively; expandable to 128 FBM with FEM100; overall I/O points up to 256 via remote I/O links

Functional Features:

  • Redundant, fault-tolerant operation with automatic switchover
  • Real-time data acquisition, alarm detection, and notification
  • Supports regulatory, sequential, and logic control strategies
  • Self-hosting mode enables startup and operation without host workstation
  • Bit-matching data consistency checks between redundant modules
  • Integration with Foxboro InTouch/Wonderware System Platform and Evo software stack

Application Scenarios:

  • Distributed control for process units in refining, petrochemicals, power generation
  • Critical loops requiring high availability and redundancy
  • Skid-mounted or remote I/O subsystems close to the process
  • Modernization projects requiring seamless integration with existing I/A Series infrastructure

Performance Parameters:

  • High-speed deterministic execution of control strategies
  • Low-latency communication over Ethernet to supervisory systems
  • Scalable I/O capacity with support for remote I/O expansion

Material and Structural Characteristics:

  • Rugged, sealed enclosure designed for unventilated cabinets
  • DIN-rail or panel-mountable within control cabinets
  • Industrial-grade components conformally coated for resistance to humidity and contaminants

Working Principle: The module executes control strategies (PID, logic, sequences) in real time, gathering data from FBM I/O modules via the fieldbus and sending setpoints. In redundant configurations, two modules run in parallel, exchanging information and performing bit-matching to ensure consistency. If a fault is detected in one module, the other takes over without disturbing the process. Installation Requirements:

  • Mount in a suitable control cabinet with proper grounding and bonding
  • Connect redundant power supplies and network links (Ethernet)
  • Terminate fieldbus connections to FBM/FEM baseboards per system diagrams
  • Configure IP addresses, redundancy settings, and control strategies using Foxboro engineering tools

Usage Notes:

  • Ensure cooling and airflow meet environmental class requirements
  • Perform periodic diagnostics checks and monitor health indicators
  • Before hot-swapping redundant modules, verify redundancy status and follow manufacturer procedures
  • Keep firmware updated to maintain security and feature compatibility
