Description
Foxboro P0916CC
- Technical Specifications
- Type: Compression Termination Assembly (CTA)
- Associated Module: FBM237 (8-channel redundant analog input)
- Input Signal Compatibility: Supports analog signals such as 4–20 mA, with connections for redundant field wiring paths as required by the module
- Terminals: Compression-style screw terminals for secure, low-resistance connections
- Environmental: Designed for industrial environments with operating temperature ranges compatible with I/A Series modules
- Materials: Insulating body and metal contacts rated for analog signal levels
- Functional Features
- Provides termination points for redundant analog input channels, supporting dual-pair wiring where required
- Ensures reliable signal transmission and isolation consistent with FBM237 specifications
- Modular design facilitates hot-swap of the module without disturbing field wiring
- Supports high-accuracy analog measurements by maintaining signal integrity
- Application Scenarios
- Redundant analog input applications in critical process loops (e.g., pressure, flow, level)
- Process industries requiring high availability and accuracy for analog measurements
- Systems where redundancy and diagnostics are essential for safety and operational continuity
- Performance Parameters
- Maintains signal integrity for low-level analog signals over industrial temperature ranges
- Supports the high accuracy and diagnostic coverage of the FBM237 module
- Provides isolation and protection consistent with I/A Series standards
- Material and Structural Characteristics
- Compression terminals designed for long-term reliability and resistance to vibration
- Robust housing materials protect against dust, humidity, and mechanical stress
- Clear channel and redundancy labeling aid in maintenance and troubleshooting
- Working Principle
- The termination assembly routes analog field signals to the FBM237 module via compression screw terminals. Redundant wiring paths are provided to support the module’s redundant architecture, ensuring continuous operation even if one path fails.
- Installation Requirements
- Mount the assembly in an enclosure or cabinet adjacent to the FBM237 module
- Connect field analog signal wiring using shielded twisted-pair cables for noise immunity
- Ensure proper grounding and shielding practices to maintain signal quality
- Verify that redundant paths are correctly wired per system diagrams
- Usage Notes
- Use shielded cables and proper grounding to minimize noise on analog inputs
- Periodically check terminal tightness and signs of corrosion
- Replace only with the same P0916CC part number to maintain compatibility and redundancy
