Description
Foxboro P0917YZ
Technical Specifications
- Part Number: P0917YZ.
- Product Type: Field Control Processor 270.
- CPU: AMD Elan SC520 @ 100 MHz.
- Storage: 32 MB Flash for non-volatile storage.
Functional Features
- Universal Compatibility: The standard-bearer for the FCP270 line, supporting all standard I/A Series software versions.
- Redundancy Ready: Hardware-prepared for 1:1 hot-standby fault-tolerant operation.
- Alarm Management: Dedicated hardware resources for rapid alarm detection.
Application Scenarios
The go-to controller for greenfield projects and brownfield replacements across refining, chemical processing, and utility sectors.
Performance Parameters
- Max Power: 8.5 W.
- Dimensions: 14.7 cm x 5.15 cm x 11.4 cm.
- Weight: 0.6 kg (net).
Material Composition
High-grade die-cast aluminum chassis. Internal PCBs use multi-layer FR4 material with high-Tg ratings.
Structural Characteristics
Features a distinct label with the P0917YZ part number. Includes integrated fiber optic transceiver ports.
Working Principle
Acts as the master node on the local fieldbus segment, polling slave FBMs, executing PID and logic blocks, and synchronizing with the redundant peer.
Installation Requirements
Mount vertically or horizontally. Ensure 100 Mbps fiber links are connected correctly.
Usage Precautions
Store in anti-static packaging. Do not apply power if the module shows physical damage.
