Description
GE 531X111PSHALG1
Technical Specifications
- Product Type: Power Supply / Module Rack
- Slot Capacity: Typically accommodates 15 single-width slots and 8 double-width slots
- Power Type: RX7i-style high-power supply support
- Dimensions: Approximately 11.15 inches (283 mm) in height and 19 inches (483 mm) in width
Functional Features
- High-Density Housing: Provides a robust physical framework for mounting multiple automation modules.
- Stable Power Distribution: Ensures reliable power delivery to all inserted modules.
- Rear I/O Access: Designed as a rear-access module rack for streamlined field wiring.
Application Scenarios
Widely deployed in complex industrial automation systems, Distributed Control Systems (DCS), and Programmable Logic Controller (PLC) setups requiring high reliability and flexible expansion.
Performance Parameters
- Module Spacing: 0.8 inches (2.3 mm) between module connectors.
- Cooling: Supports additional cooling fan installation based on specific thermal load requirements.
Material Composition
Constructed from heavy-duty industrial-grade metals and high-temperature resistant plastics to withstand harsh factory environments.
Structural Characteristics
Standard 19-inch rack-mountable form factor with precision-machined backplane connectors and a durable front panel.
Working Principle
Receives primary AC or DC power, conditions it, and distributes regulated voltages across the backplane to power the CPU and I/O modules while providing a high-speed data bus for inter-module communication.
Installation Requirements
Must be securely mounted in a standard 19-inch equipment cabinet. Adequate clearance must be maintained around the unit to ensure proper airflow and cooling.
Usage Precautions
Always disconnect power before inserting or removing modules. Ensure the backplane connectors are fully seated and avoid touching the exposed metal pins to prevent electrostatic discharge (ESD) damage.
