Description
GE 531X111PSHAWG3
Technical Specifications
- Product Type: Power Supply / Module Rack
- Slot Capacity: Supports multiple single-width and double-width modules
- Power Type: High-capacity industrial power supply
- Compatibility: RX7i-style modules and VME devices
Functional Features
- Robust Power Distribution: Delivers stable, regulated voltages to all inserted modules.
- High-Speed Backplane: Facilitates rapid data exchange between CPU and I/O modules.
- Flexible Expansion: Accommodates a mix of module types for customized system configurations.
Application Scenarios
Distributed Control Systems (DCS), Programmable Logic Controllers (PLC), and industrial process automation.
Performance Parameters
- Module Spacing: 0.8 inches (2.3 mm) between connectors.
- Cooling: Supports forced-air cooling for high-density configurations.
Material Composition
Heavy-duty metal chassis with precision-machined backplane connectors and industrial-grade plastics.
Structural Characteristics
19-inch rack-mountable form factor with rear I/O access and front-panel status indicators.
Working Principle
Receives primary power, converts it to regulated DC voltages, and distributes both power and data across the backplane to all installed modules.
Installation Requirements
Securely mount in a standard 19-inch cabinet. Maintain adequate clearance for airflow and ensure proper chassis grounding.
Usage Precautions
Always disconnect power before modifying the rack configuration. Verify that the total power draw of installed modules does not exceed the power supply’s capacity.
