GE 6KP1143030X1B1
Technical Specifications
- Product Series: GE Fuji AF-300 P11 Drive.
- Power Rating: 30 Horsepower (HP).
- Voltage Rating: 460V 3-Phase.
- Part Number: 6KP1143030X1B1.
Functional Features
- Variable Frequency Control: Provides precise speed and torque control for AC induction motors.
- Advanced Protection: Integrated protection against overcurrent, overvoltage, and motor overload.
- User-Friendly Interface: Features an intuitive digital operator panel for easy parameter configuration and monitoring.
- Energy Efficiency: Optimizes motor power consumption based on load requirements.
Application Scenarios
Widely utilized in industrial automation, HVAC systems, pump and fan control, conveyor systems, and general manufacturing machinery.
Performance Parameters
- Input/Output: 3-Phase 460V AC input with variable frequency output.
- Control Accuracy: High-precision speed and torque regulation.
Material Composition
Enclosed in a durable industrial-grade metal chassis, containing high-power IGBT modules, microprocessors, and heat-dissipating components.
Structural Characteristics
Compact NEMA-compliant enclosure design featuring front-panel digital display, keypad navigation, and rear power/signal terminal blocks.
Working Principle
Converts incoming fixed-frequency AC power to DC, then uses an inverter section to synthesize a variable-frequency, variable-voltage AC output to precisely control motor speed and torque.
Installation Requirements
- Mount vertically in a clean, dry environment with adequate clearance for airflow.
- Connect 460V 3-phase power to the designated input terminals and motor leads to the output terminals.
- Ensure proper grounding of the drive chassis and motor.
Usage Precautions
- Never connect power to the output terminals; this will cause catastrophic damage.
- Allow internal capacitors to fully discharge before servicing.
- Ensure cooling fans are unobstructed during operation.
