Description
GE A05B-2518-C204
Technical Specifications
- Component Type: Teach Pendant / Operator Interface
- Series: GE Fanuc Robotics
- Interface: Integrated LCD display, membrane keypad, and emergency stop button.
Functional Features
- Allows manual jogging of robot axes for precise positioning.
- Provides a platform for writing, editing, and testing robot programs.
- Displays real-time system status, alarms, and diagnostic information.
Application Scenarios
Used in automated manufacturing, welding, assembly, and material handling cells utilizing GE Fanuc robotic systems.
Performance Parameters
- Ergonomic design for extended handheld use.
- Durable membrane switches rated for millions of actuations.
Material Composition
High-impact industrial plastic housing with a reinforced coiled cable and strain relief.
Structural Characteristics
Compact, lightweight handheld unit featuring a digital display, navigation keys, axis selection switches, and a prominent red E-Stop button.
Working Principle
Communicates with the robot controller via a dedicated serial or proprietary bus, translating operator keypresses into digital commands that control the robot’s servo drives.
Installation Requirements
- Connect securely to the designated teach pendant port on the robot controller.
- Ensure the cable is routed to prevent tripping hazards or crushing.
- Verify that the E-Stop circuit is functional before operation.
Usage Precautions
- Never operate the robot without verifying the E-Stop functionality.
- Protect the pendant from excessive drops, oil, and coolant exposure.
- Inspect the cable regularly for fraying or internal wire breaks.
