Description
GE C216LI
Technical Specifications:
- Brand: General Electric (GE)
- Model: C216LI
- Product Type: Molded Case Circuit Breaker (MCCB)
- Poles: 3-Pole
- Voltage Rating: 600V AC
Functional Features:
- Thermal-Magnetic Protection: Utilizes a dual-element trip mechanism to protect against both prolonged overloads and instantaneous short circuits.
- High Interrupting Capacity: Engineered to safely clear severe short-circuit currents without catastrophic failure.
- Rugged Enclosure: Housed in a durable, flame-retardant thermoplastic case for maximum operator safety and arc containment.
Application Scenarios:
Widely deployed as main feeders or large branch circuit protectors in industrial manufacturing plants, commercial high-rises, and heavy machinery power panels.
Performance Parameters:
- Continuous Current: Rated for high continuous load capacity without derating under standard conditions.
- Mechanical Life: Exceptional cycle life for frequent switching, testing, and maintenance operations.
Material Composition:
Encased in high-impact, glass-filled thermoplastic. Internal contacts are crafted from silver-alloy composites to minimize resistance and resist arcing degradation.
Structural Characteristics:
Features a compact, space-saving design with clear ON/OFF/TRIP indicator markings and a manual operating handle for positive visual confirmation.
Working Principle:
Acts as a manual switch under normal conditions. During an overload, a bimetallic strip heats and bends to trip the mechanism; during a short circuit, an electromagnetic solenoid instantly unlatches the contacts.
Installation Requirements:
Must be mounted in a properly rated electrical enclosure. Ensure adequate clearance for heat dissipation and torque all terminal connections to the manufacturer’s exact specifications.
Usage Precautions:
Always perform lockout/tagout (LOTO) procedures before servicing. Never exceed the rated voltage or current capacity, and regularly exercise the breaker to maintain mechanical reliability.
