Description
GE CR115E724101
Technical Specifications
- Series: GE CR115.
- Part Number: CR115E724101.
- Type: Electromechanical Control Relay.
- Coil Voltage: Specific to part configuration.
Functional Features
- Versatile Contacts: Multiple Form C (SPDT) or Form A/B contacts for flexible logic.
- High Mechanical Life: Rated for millions of operations.
- Fast Response: Quick operate and release times for precise control.
- Visual Indication: Optional mechanical flag or LED for coil status.
Application Scenarios
Used in PLC output interfaces, motor control circuits, safety interlocks, and industrial automation logic.
Performance Parameters
- Contact Rating: Rated for standard control loads (e.g., 10A at 600VAC).
- Dielectric Strength: High isolation between coil and contacts.
- Operate Time: Millisecond-level response.
Material Composition
Silver-alloy contacts, phenolic or thermoplastic housing, copper coil windings, and steel magnetic core.
Structural Characteristics
Plug-in or panel-mount configuration. Features octal or blade terminals. Optional transparent cover for contact inspection.
Working Principle
Energizing the coil creates a magnetic field that moves the armature, mechanically switching the contacts to control external circuits.
Installation Requirements
Use appropriate socket or mount securely to panel. Ensure proper coil voltage and polarity (if DC).
Usage Precautions
Do not exceed contact ratings. Use surge suppression for inductive loads. Replace if contacts show excessive wear or pitting.
